Aguilar OBP-3TK Onboard Preamp

Brand: Aguilar

Color: Black

Features:

• Includes separate Treble, Mid, and Bass pots,
• plus/minus 18dB bass at 40Hz
• plus/minus 16 db of cut and boost at either 400Hz or 800 Hz
• plus/minus 16 dB @ 6.5KHz
• Battery life: 324 hours

Binding: Electronics

Release Date: 18-06-2008

model number: OBP-3TK

Part Number: OBP-3TK

Details: Product Description The OBP-3 is Aguilar's most flexible onboard preamp design, providing +/-18dB of cut and boost at 40Hz, +/- 16dB of cut and boost at either 400Hz or 800Hz and +/- 16dB of treble cut and boost at 6.5 kHz. The OBP-3 has multiple wiring options, and can be wired with either a mini-toggle or internal dip-switch for midrange frequency selection. Amazon.com The OBP-3 is Aguilar's most flexible onboard preamp design, providing +/-18dB of cut and boost at 40Hz, +/- 16dB of cut and boost at either 400Hz or 800Hz and +/- 16dB of treble cut and boost at 6.5 kHz. The OBP-3 has multiple wiring options, and can be wired with either a mini-toggle or internal dip-switch for midrange frequency selection. The OBP-3TK includes separate Treble, Mid, and Bass pots,and a black mini-toggle switch for Midrange frequency selection. Bass control: plus/minus 18 dB @ 40 Hz. Mid control: plus/minus 16 dB @ 400Hz or 800 Hz. User selectable frequency center. Treble control: plus/minus 16 dB @ 6.5 KHz. Input impedance: 1 meg ohm Output impedance: 100 ohm 9 or 18 volts operation. Additional 6dB with 18 volts. Distortion: .019 into 10k ohm load Noise: -95 dBm unweighted. Battery life: 324 hours Wire lead length: 6.50 inches Low noise discrete FET input stage, center detent 50 K linear pots,with a dual concentric pot available. Dimensions: 0.98"W x 0.98"L x 0.59"D Warranty: Three year limited warranty.

EAN: 0824599000094

Package Dimensions: 4.7 x 3.3 x 2.3 inches

Languages: English
